Showing 31–45 of 115 results
-
Thickness Standards are used to verify the accuracy and operation of coating thickness gauges. As a component of ISO 9000 or in-house quality control procedures, they are a practical alternative to sending instruments to DeFelsko for calibration. These Plastic Shims (aka foils) are low-cost alternative to coated metal plates. They are available in Certified (individual shims or full sets) and in Un-Certified sets. Accuracy is somewhat less than metal plates and they are more sensitive to heat. They are intended for use over a Zero Plate, or over an uncoated substrate. A set of un-certified plastic shims is included with most electronic DeFelsko coating thickness gauges. Replacement sets and certified options are available here as follows:- Un-Certified. These are checked for accuracy within tolerance shown below at DeFelsko, but are not traceable to any standard. They come as a set of 5 only, in the following approximate thicknesses:
- 25 microns / 1 mil (Orange), +- 20% accuracy
- 50 microns / 2 mils (Red), +- 10% accuracy
- 125 microns / 5 mils (Blue), +- 5% accuracy
- 250 microns / 10 mils (Brown), +- 5% accuracy
- 500 microns / 20 mils (Yellow), +- 5% accuracy
- Certified. Includes certificate of calibration traceable to PTB and all are accurate to within 2 microns / 0.08 mils. Available in the following thicknesses individually, or as a complete set of 8 shims:
- 25 microns / 1 mil (Orange)
- 50 microns / 2 mils (Red)
- 75 microns / 3 mils (Green)
- 125 microns / 5 mils (Blue)
- 250 microns / 10 mils (Brown)
- 500 microns / 20 mils (Yellow)
- 1000 microns / 40 mils (White)
- 1500 microns / 60 mils (Black)
- Un-Certified. These are checked for accuracy within tolerance shown below at DeFelsko, but are not traceable to any standard. They come as a set of 5 only, in the following approximate thicknesses:
-
Part Number Purchase Price INDPOSIPEN $498.13 Web price iPlease sign in to your account to see your pricing, which may be different from the price displayed.$498.13
-
-
The PosiTector® 6000 probe & advanced gage / body kit family - DeFelsko's premium solution for non-destructive coating thickness measurement on metallic* substrates. The PosiTector 6000 series is the most extensive range of instrument probes that DeFelsko offers - many versions available for many different applications. Further details as follows:
- Familiar. The PosiTector Gauge / Body is the tried-and-true platform offering interchangeability with most DeFelsko probes.
- Versatile. Checks coating thickness in many applications, including:
- Single-handed use (integral probes)
- Cabled probes in various lengths
- Hot / Rugged applications
- Very thin to very thick coatings
- and more!
This page shows Kit / Packages for the Advanced Body with your choice of PosiTector 6000 probe. (Compare the features of the PosiTector Standard and Advanced Body on their separate page.) Other configurations (Probe-only, Body-only and Standard Body / Probe kits) are shown on their separate pages.
Probes - not the Gage / Bodies - are factory calibrated and each new probe comes with a Certificate of Calibration. For field calibration checks, certified or non-certified standards are available separately (see You May Also Like below.) Contact us for information on probe repairs or probe re-certifications.
*The DeFelsko PosiTector 200 is available for measuring coating thickness on non-metallic substrates.
-
The PosiTector® 6000 probe & standard gage / body kit family - DeFelsko's basic solution for non-destructive coating thickness measurement on metallic* substrates. The PosiTector 6000 series is the most extensive range of instrument probes that DeFelsko offers - many versions available for many different applications. Further details as follows:
- Familiar. The PosiTector Gauge / Body is the tried-and-true platform offering interchangeability with most DeFelsko probes.
- Versatile. Checks coating thickness in many applications, including:
- Single-handed use (integral probes)
- Cabled probes in various lengths
- Hot / Rugged applications
- Very thin to very thick coatings
- and more!
This page shows Kit / Packages for the Standard Body with your choice of PosiTector 6000 probe. (Compare the features of the PosiTector Standard and Advanced Body on their separate page.) Other configurations (Probe-only, Body-only and Advanced Body / Probe kits are shown on their separate pages.
Probes - not the Gage / Bodies - are factory calibrated and each new probe comes with a Certificate of Calibration. For field calibration checks, certified or non-certified standards are available separately (see You May Also Like below.) Contact us for information on probe repairs or probe re-certifications.
*The DeFelsko PosiTector 200 is available for measuring coating thickness on non-metallic substrates.
-
INDUSBACThe DeFelsko® AC Power Kit is the ultimate solution for uninterrupted use of your battery-operated PosiTector® devices. This versatile kit enables continuous operation without reliance on batteries, featuring a USB cable for direct connection to a PC and an AC power adapter for wall outlets. Compatible with PosiTector® 6000, 200, SPG, RTR H, RTR 3D, DPM, IRT, SST, UTG, SHD, BHI, and GLS models with serial numbers greater than 864000, it includes a selection of electrical plugs to accommodate various international outlets, ensuring your PosiTector® is always ready for action, whether in the lab, on the production floor, or in the field.
- Designed for uninterrupted use of PosiTector® devices
- Includes USB cable and AC power adapter for versatile power options
- Compatible with a wide range of PosiTector® models
- Selection of electrical plugs for international compatibility
- Ideal for continuous operation without battery dependency
INDUSBACThe DeFelsko® AC Power Kit is the ultimate solution for uninterrupted use of your battery-operated PosiTector® devices. This versatile kit enables continuous operation without reliance on batteries, featuring a USB cable for direct connection to a PC and an AC power adapter for wall outlets. Compatible with PosiTector® 6000, 200, SPG, RTR H, RTR 3D, DPM, IRT, SST, UTG, SHD, BHI, and GLS models with serial numbers greater than 864000, it includes a selection of electrical plugs to accommodate various international outlets, ensuring your PosiTector® is always ready for action, whether in the lab, on the production floor, or in the field.
- Designed for uninterrupted use of PosiTector® devices
- Includes USB cable and AC power adapter for versatile power options
- Compatible with a wide range of PosiTector® models
- Selection of electrical plugs for international compatibility
- Ideal for continuous operation without battery dependency
-
IND6000CASENYLON- Protects gage, probe and accessories during storage and transportation
- Made of durable nylon
- Manufacturer part #CASENYLON-G
IND6000CASENYLON- Protects gage, probe and accessories during storage and transportation
- Made of durable nylon
- Manufacturer part #CASENYLON-G
Part Number Purchase Price IND6000CASENYLON $209.92 Web price iPlease sign in to your account to see your pricing, which may be different from the price displayed.$209.92
-
-
The PosiTector® CMM IS - DeFelsko's solution for In Situ Concrete Moisture Metering conforming to ASTM F2170 testing standards. Innovative and simple to use, this PosiTector Concrete Moisture Meter offers the highest levels of testing accuracy, helping to prevent costly concrete coating failures. Selected features as follows:- Simple Design. Individual In-Situ meters, inserted into holes drilled into concrete, connect wirelessly to the PosiTector App, or to a PosiTector Advanced Gage/DPM probe.
- Capable. The PosiTector CMMIS offers the most accurate moisture measurement in concrete as it detects moisture levels well below the floor surface.
- Configurable. With various expandable package options, the CMM IS platform can test on any size concrete floor, as follows:
- 3 probe Basic Kit, including caps, probe sleeve extensions, calibration check chambers and other accessories required for testing.
- 5 probe Complete Kit, including all the above plus a carrying case and a vacuum tool for cleaning out the drilled holes.
- 5 Probe Pro Kit, combines a PosiTector Advanced Gage/DPM probe with the above Complete Kit.
-
The PosiTector® DPM - DeFelsko's solution for measurement of climatic conditions for industrial coating applications. Versatile and capable, these environmental measuring instruments have the following highlights:- Familiar. Built on the tried-and-true PosiTector® gauge/body platform design with interchangeable probes.
- Capable. Measures and records environmental conditions including:
- Relative Humidity (RH)
- Air Temperature
- Surface Temperature
- Dew Point temperature
- Surface/Dew Point Delta
- Wind speed (one model only)
- Wet-Bulb (when used with Advanced Bodies only)
- Configurable. Available as probes-only (to use with an existing gage/body), or in packages with a new gage body, these DPM probes are available as:
- DPM Integral, with direct-contact surface thermometer
- DPMIR Integral, with infrared surface thermometer, for use on moving parts, very hot parts, etc., where direct contact is not possible.
- DPMS Integral, with cabled, magnetic surface temperature sensor for continuously logging surface temperatures. Also available for this model are 2 options:
- A liquid temperature probe, for measuring paint temperature prior to application
- A hand-held surface temperature probe, for spot-checking hard-to-reach areas.
- DPMA Integral, with all standard features plus a wind-speed indicator
- DPMD Cabled, with ½" NPT threads for insertion into pipe and other areas that can't be accessed by other versions.
-
The PosiTector IRT - DeFelsko's solution for dedicated, non-contact temperature measurement. It is rich in features, as follows:- Familiar. Built on the tried-and-true PosiTector® platform with the interchangeable probe design.
- Capable. Works where conventional sensors cannot, it measures surface temperatures on moving parts, hard-to-reach areas, and objects whose temperatures are higher than the range of direct-contact sensors.
- Economical. When measurement of other climatic conditions is not required, this PosiTector IRT saves money vs. the higher-featured PosiTector DPM IR.
- Configurable. Available as follows:
- Probe-only (use with existing gauge / body)
- Package with Standard gauge / body
- Package with Advanced gauge / body
-
IND6000PFR- Ideal for use on thin, soft coatings
- Pack includes 2 nylon foot rings, instruction card and clear plastic case
- Compatible with all PosiTector 6000 regular separate probes (FS, FTS, NS, NAS, FNS)
- Manufacturer part # PRBFOOTKIT-D
IND6000PFR- Ideal for use on thin, soft coatings
- Pack includes 2 nylon foot rings, instruction card and clear plastic case
- Compatible with all PosiTector 6000 regular separate probes (FS, FTS, NS, NAS, FNS)
- Manufacturer part # PRBFOOTKIT-D
Part Number Purchase Price IND6000PFR $62.66 Web price iPlease sign in to your account to see your pricing, which may be different from the price displayed.$62.66
-
-
INDSSTABRKITThe DeFelsko® PosiTector® SST Abrasives Test Kit measures soluble salts in blast cleaning abrasives. Designed for compliance with ASTM D4940 and ISO 11127-6, this portable kit includes everything needed to accurately assess contamination levels: two glass beakers, one plastic beaker, a plastic funnel, paper filters, 1L deionized water, 60ml certified conductivity standard, and a stainless mixing rod, all encased in a durable plastic case. Ensure the purity of your abrasives and the quality of your surface preparation with ease.- Designed for ASTM D4940 and ISO 11127-6 compliance.
- Portable kit includes glass and plastic beakers, funnel, filters, deionized water, conductivity standard, and mixing rod.
- Enables accurate measurement of soluble salt contamination in abrasives.
- Includes certified conductivity standard for meter accuracy verification.
- All components neatly organized in a hard plastic case for field or lab use.
INDSSTABRKITThe DeFelsko® PosiTector® SST Abrasives Test Kit measures soluble salts in blast cleaning abrasives. Designed for compliance with ASTM D4940 and ISO 11127-6, this portable kit includes everything needed to accurately assess contamination levels: two glass beakers, one plastic beaker, a plastic funnel, paper filters, 1L deionized water, 60ml certified conductivity standard, and a stainless mixing rod, all encased in a durable plastic case. Ensure the purity of your abrasives and the quality of your surface preparation with ease.- Designed for ASTM D4940 and ISO 11127-6 compliance.
- Portable kit includes glass and plastic beakers, funnel, filters, deionized water, conductivity standard, and mixing rod.
- Enables accurate measurement of soluble salt contamination in abrasives.
- Includes certified conductivity standard for meter accuracy verification.
- All components neatly organized in a hard plastic case for field or lab use.
Part Number Purchase Price INDSSTABRKIT $1,228.10 Web price iPlease sign in to your account to see your pricing, which may be different from the price displayed.$1,228.10
-
-
The PosiTector UTG - DeFelsko's solution for measurement of wall thicknesses of pipes, tanks, and more where access is limited to one side. Here are some highlights of the highly capable DeFelsko ultrasonic thickness gage probe family:- Familiar. The UTG family of probes are interchangeable with the tried-and-true DeFelsko gage body platform.
- Capable. Six different probe versions are available, depending on the requirements of the application. The first four are standard corrosion single-echo probes designed for applications where the surface is unpainted (or has the paint removed.)
- PRBUTGC: Standard frequency 5mz transducer. Cabled.
- PRBUTGCX: Xtreme version of above with a braided stainless cable with strain relief for demanding use.
- PRBUTGCA: Same as above, except integral non-cabled design. This version is ideal for one-handed use.
- PRBUTGCLF. Low-frequency 2.25mz transducer for attenuative materials like cast iron. Standard cable.
- The following two models are both cabled, and can be used on either painted or non-painted substrates.
- PRBUTGM: 5mz transducer with highly versatile single and multi-echo modes. Single mode offers greater (up to 5 inches thick) measurement range, but should be used where paint has been removed. Multi-echo mode does not require the paint to be removed and can measure walls up to 2.5 inches thick. This version has a durable alumina wear face and is ideal for use on rough or blasted surfaces.
- PRBUTGP: 15mz transducer offers high precision when measuring thin materials (up to .475 inch thick steel or up to .175 inch thick plastic). It has automatic single / multi echo mode switching for use on painted or unpainted surfaces. This probe can be used to measure thicknesses of plastic bottles, aircraft windows, thin-wall pipe, and much more.
- Configurable. Any of the six probes can be configured in the following packages:
- Probe only. Use with your existing PosiTector gauge.
- Standard PosiTector package with choice of probe.
- Advanced PosiTector package with choice of probe.
- Note: All PosiTector UTG packages come with case, ultrasonic gel, calibration certificate, and more.
-
-
The PosiTest® AT series - DeFelsko's answer for testing coating adhesion on multiple substrates. Practical and capable, this product family offers a professional way to conform to recognized standards, including ASTM D4541 / D7234 and ISO 4624.
Highlights are as follows:
- Multiple Versions:
- Economical Manual hydraulic pump, with new display and internal memory holding up to 200 pulls. Compatible with PosiSoft Desktop.
- Capable Automatic hydraulic pump, reduces user effort and risk of user influence on result. Internal memory for up to 100,000 pulls in 1000 batches. Compatible with PosiSoft Desktop, PosiSoft.net, and PosiTector app
- Versatile. Both Manual and Automatic versions can be configured for 1 of 4 applications. And optional conversion kits are available if switching from one application to another is needed. Application options are:
- 20mm, Higher bond strength coatings on metals
- 50mm, Lower bond strength coatings on concrete, wood, and plastic
- 50 x 50mm Tiles, Cementitious adhesives for tiles
- 50mm C1583, Concrete surfaces and overlays
- Complete. Each Adhesion Tester comes with everything needed for testing, including:
- Selected Instrument
- Dollies per option selected
- Batteries
- Lightweight case
- Calibration certificate, and more!
Note: Premium Pelican carrying case optionally available for the Automatic tester.
PosiTest® AT replacement dollies and conversion kits (for using in additional applications) as well as additional PosiTest Adhesive tubes are all separately available.
- Multiple Versions:
