The RPB T-Link Paint Respirator is a painting hood designed for optimum comfort and visibility for painting contractors. The hood is designed to turn with the operator’s head, and its large visor enables excellent downward and peripheral vision while wearing the hoods, while the fixed lens frame prevents the lens from rubbing up against the operator’s nose. The T-Link also features a ratchet-adjustable padding system to ensure a secure, evenly balanced fit—making it feel lighter and eliminating pressure points on the operator’s head.
APPLICATIONS
This respirator is typically used to protect and provide clean airflow to a painting contractor in an industrial coating or painting setting. It can also be fitting with cooling air systems to ensure maximum operator comfort while on the job.
SPECIFICATIONS
Securely attached hood to prevent it from blowing up off the operator’s head
2 types of head protection: Bump Cap and Hard Hat
Full visor frame to prevent the lens from hitting operator’s nose
Soft breathable inner bib with draw cord
Long tuck-in collar for extra protection and upper body airflow
Simple breathing tube attachment via Swivel Inlet fittings
Helmet padding with ear protect and ratchet adjustment
If you need compliance to have a respirator with a ANSI Z87+ Safety Lens, we recommend using the Zlink from RPB
Communication system upgrades available
Item No.
Description
Part No.
Mfg Part No.
1.
T-LINK Respirator Hood
See Below
See Below
2.
T-LINK Lightweight Helmet Shell
HAT17511
17-511
3.
LINK System Hard Hat Helmet Shell
HAZ16511
16-511
4.
LINK System Jaw
HAZ16514
16-514
5.
T-LINK Lens Clips (Left and Right Pair)
HAT15512
15-512
6.
LINK COMFORT-LINK
HAZ520T
16-520-T
7.
LINK System Impact Absorber
HAZ16521
16-521
8.
LINK System Comfort Pad
HAZ16522
16-522
9.
LINK System Head Harness Bracket and Air Director
HAZ16525
16-525
10.
LINK System Head Harness
HAZ16531
16-531
11.
LINK System Ratchet Adjuster Assembly
HAZ16530
16-530
12.
LINK System Head Harness Brow Pad
HAZ16526
16-526
13.
LINK System Side Padding System
HAZ16520S
16-520-S
14.
LINK System Side Padding Frames
HAZ16527
16-527
15.
LINK System Foam Side Pads
HAZ16528
16-528
16.
LINK System Breathing Tube for PX4 AIR PAPR
HAZL04835
04-835
LINK System Breathing Tube for Supplied Air
HANVZ830
04-830
17.
PX4 AIR PAPR and Belt
HAP3901G
03-901
18.
PX4 Air Flow Tester
HAPX404091
04-091
19.
Constant Flow Valve Assembly
HANVT3101
03-101
20.
C40 Climate Control Assembly and Belt
HLCCD3501
03-501
21.
Belt
HLNV2022
NV2022
22.
T-LINK Tear-Off Lenses
HAT17811
17-811
23.
Quiet-LINK Helmet Earmuffs
HANVZ18533
18-533
The T-Link was designed for industrial applications and offers the following features:
Robust construction with interior face-frame design (Improves comfort by keeping the lens off the operators face)
Large viewing window with maximum downward and peripheral vision
Soft, breathable inner-bib and extra tuck-in collar
Several Configurations / Options available as follows:
Choose your Air Supply type
Constant flow valve – use with breathing air line. Offers basic volume control without heating/cooling
C40 – use with breathing air line. Premium variable temperature control – up to 52° cooling or 33° heating
HX5 PAPR – Single speed battery powered unit. Does not use breathing air line for maximum portability. Does not heat or cool.
PX5 PAPR – Three speed battery powered unit. Does not use breathing air line for maximum portability. Does not heat or cool.
NOTE – PAPR units are NOT currently rated for explosive environments. Contact us for status of Intrinsically Safe units currently in development.
Choose your head protection
Bump Cap – light-weight, non-rated head protection
Hard Hat – Z89.1, Type 1, Class C Hard Hat protection
Choose your Tyvek type
Tychem 2000 hood for splash protection
Tychem 4000 hood with sealed seams for chemical protection (often used by powdercoaters)
Optional Vision-Link™ light – chin mounted for improved view in dim settings. NOTE – This is NOT currently rated for explosive environments. Enquire for status of intrinsically safe version.
Optional Quiet-Link™ ear muffs with suspension bracket for hearing protection.
Optional Comms-Link™ in-helmet communication system. Pairs with existing 2-way radio. Note – this option is NOT rated for explosive environments.
Modular Design – every part can be replaced for maintenance purposes
Genuine Product – Manufactured by GVS / RPB Safety in USA
