Designation | Profile Distance | Profile Surface Area per metre | Profile Surface Area per tonne | Profile Distance Less One Flange Face | Profile Surface Area Less Ara of One Flange Face per metre | Profile Surface Area Less Ara of One Flange Face per tonne | |
mm | sqm/m | sqm/tonne | mm | sqm/m | sqm/tonne | ||
Taper Flange Beams | |||||||
178 x 89 | 658 | 0.658 | 29.4 | 569 | 0.569 | 25.4 | |
152 x 76 | 562 | 0.562 | 31.4 | 486 | 0.486 | 27.2 | |
125 x 65 | 470 | 0.470 | 35.7 | 405 | 0.405 | 30.8 | |
100 x 45 | 349 | 0.349 | 48.5 | 304 | 0.304 | 42.2 | |
Channels | |||||||
380 x 100 | 1130 | 1.13 | 20.7 | 1030 | 1.03 | 18.8 | |
300 x 90 | 932 | 0.932 | 23.2 | 842 | 0.842 | 21.0 | |
250 x 90 | 834 | 0.834 | 23.5 | 744 | 0.744 | 21.0 | |
230 x 75 | 737 | 0.737 | 29.4 | 662 | 0.662 | 26.4 | |
200 x 75 | 678 | 0.678 | 29.6 | 603 | 0.603 | 26.4 | |
180 x 75 | 638 | 0.638 | 30.5 | 563 | 0.563 | 26.9 | |
150 x 75 | 580 | 0.580 | 32.8 | 505 | 0.505 | 28.5 | |
125 x 65 | 480 | 0.480 | 35.7 | 415 | 0.415 | 30.9 | |
100 x 50 | 374 | 0.374 | 40.0 | 324 | 0.324 | 34.6 | |
74 x 40 | 286 | 0.286 | 43.0 | 246 | 0.246 | 37.0 | |
Junior Universal Beams | |||||||
180 UB | 22 | 691 | 0.691 | 31.1 | 601 | 0.601 | 27.1 |
18 | 685 | 0.685 | 37.8 | 595 | 0.595 | 32.9 | |
150 UB | 18 | 584 | 0.584 | 32.4 | 509 | 0.509 | 28.3 |
14 | 576 | 0.576 | 41.1 | 501 | 0.501 | 35.8 |
Superior know how
Taper Flange Beams, Channels and Junior Universal Beams
